Technical Product Details
| Material Grade | Stainless Steel 316 (UNS S31600) |
| Governing Specifications | ASTM A240 / ASME SA240, ASTM A666, AISI 316, JIS SUS 316, EN 10088-2, DIN, BS, GB, IS |
| Surface Finishes | BA (Bright Annealed), No.8 Mirror Polish, 8K Reflective, 2B, No.4 Hairline |
| Manufacturing Scope | Cold Rolled Narrow Strips, Precision Slitting Coils, Protective PE/PVC Film Coated |
| In-House Quality Verification | 100% PMI Handheld XRF Spectro, Rockwell Hardness Verification, Calibrated Micrometer Inspection, Optical Surface Defect Scanning |
Table of Contents
Looking for premium SS 316 BA Strip or SS 316 Mirror Strip stock engineered for severe marine, chemical, or pharmaceutical environments? Nirvaan Overseas supplies molybdenum-bearing austenitic alloys that combine superior chloride pitting resistance with a flawless optical surface.
We supply SS 316 Bright Finish Strip coils laminated with laser-compatible protective PE film to prevent surface scuffs during deep drawing, bending, and stamping. As an established SS 316 Mirror Strip Supplier in India, we support specialized engineering demands with precision narrow slitting, deburred edges, and full trace reports.
Operating as an ISO-certified SS 316 Mirror Finish Strip Exporter and Stainless Steel 316 Strip Exporter, we maintain ASTM A240 certified inventory complete with 100% PMI verification and EN 10204 3.1 MTCs for immediate global dispatch across the Middle East, Europe, Southeast Asia, and the Americas.
| Technical Parameter | Specification Scope & Processing Capabilities |
|---|---|
| Governing Specifications | ASTM A240 / ASME SA240, ASTM A666, AISI 316, JIS SUS 316, Werkstoff 1.4401, EN 10088-2, BS 316S31 |
| Grade Variant | Stainless Steel 316 (UNS S31600) |
| Form & Types | Cold Rolled Bright Annealed Strips, 8K Mirror Polished Coils, Precision Slit Narrow Ribbons |
| Dimensional Scope | Thickness: 0.05 mm to 6.0 mm | Slit Width: 3.17 mm to 1000 mm | Length: Continuous Coil / Custom Sheets |
| Edge Treatments | Precision Slit Edge, Deburred Edge, Rounded Edge, Mill Edge |
| Surface Finish | BA (Bright Annealed), No.8 Mirror Polish, 8K, 2B, No.1, No.4 Satin, Hairline |
| Surface Protection | Single / Double PE Protective Film (50–100 Micron Fiber-Laser Compatible) |
| Tempered Options | Annealed (Soft), Quarter Hard, Half Hard, Full Hard |
| Element | Specification Limits (% by weight) |
|---|---|
| Carbon (C) | 0.08% Max |
| Manganese (Mn) | 2.00% Max |
| Silicon (Si) | 0.75% Max |
| Phosphorus (P) | 0.045% Max |
| Sulfur (S) | 0.030% Max |
| Chromium (Cr) | 16.00% Min – 18.00% Max |
| Molybdenum (Mo) | 2.00% Min – 3.00% Max |
| Nickel (Ni) | 10.00% Min – 14.00% Max |
| Nitrogen (N) | 0.10% Max |
| Mechanical Property | SS 316 Strip Standard Limits |
|---|---|
| Tensile Strength (ksi / MPa min) | 75 ksi (515 MPa) Min |
| Yield Strength (0.2% Proof ksi / MPa min) | 30 ksi (205 MPa) Min |
| Elongation (% in 50 mm min) | 40% |
| Hardness (Rockwell B Max) | 95 HRB Max |
| Hardness (Brinell HB Max) | 217 HB Max |
Calculate the approximate weight of your Finish Strip:
| Feature / Requirement | SS 316 BA / Mirror Strip (UNS S31600) | SS 304 BA / Mirror Strip (UNS S30400) |
|---|---|---|
| Primary Advantage | Marine-grade chloride pitting resistance and high creep strength | Standard general-purpose corrosion resistance and deep drawability |
| Alloy Composition | 16–18% Cr, 10–14% Ni, 2–3% Mo | 18–20% Cr, 8–10.5% Ni, Balance Fe |
| Corrosion Resistance | Superior (Resists halides, chlorides, marine splash, & sulfuric acid) | High (Resists outdoor weather, moisture, & organic acids) |
| Cost & Budget | Premium alloy pricing due to molybdenum and higher nickel content | Standard economical pricing for general architectural/industrial use |
| Yield Strength | 205 MPa min (30 ksi) | 170 MPa min (25 ksi) |
| Magnetic Property | Non-Magnetic in annealed condition | Non-Magnetic in annealed condition |
| Typical Selection | Marine equipment, pharmaceuticals, chemical processing, coastal trims | Indoor/outdoor architectural trim, appliances, food processing, sinks |
| In-Stock Availability | Current Grade (Ready to Ship) | View SS 304 Specs → |
Nirvaan Overseas is a trusted SS 316 BA Strip Supplier in India and Stainless Steel 316 Strip Exporter, delivering certified prime stock with complete compliance documentation worldwide:
Mumbai
Pune
Chennai
Faridabad
Saudi Arabia
Qatar
Oman
Kuwait
Germany
Italy
Netherlands
Poland
Singapore
Malaysia
Vietnam
Indonesia
Michigan
Illinois
Texas
Every order dispatched from our ISO-certified facility undergoes rigorous quality control checks prior to shipment:
| Inspection Stage | Testing & Compliance Standard |
|---|---|
| Dimensional Verification | Calibrated Micrometer and Vernier gauge checks for precise thickness, slit width, and edge camber tolerances. |
| PMI & Chemical Testing | 100% In-House XRF Spectro testing to verify heat chemistry and 2–3% Molybdenum alloying levels. |
| Surface Inspection | Optical surface scanning to guarantee zero pinholes, scratches, rolling scale, or edge burrs. |
| MTC & Certification | Full EN 10204 3.1 / 3.2 Material Test Certificates accompanied by NABL-accredited laboratory reports. |
| Third-Party Inspection | Pre-dispatch TPI available upon request via SGS, TUV, Bureau Veritas, DNV, or Lloyds. |
A: SS 316 BA Strip is a cold-rolled molybdenum-bearing austenitic stainless steel strip bright annealed in a protective atmosphere to create a highly reflective, scale-free finish.
A: SS 316 contains 2–3% Molybdenum and higher nickel content, providing significantly higher resistance to chlorides, marine salt, and chemical pitting compared to SS 304.
A: Grade 316 is fully non-magnetic in the soft annealed condition and exhibits lower magnetic permeability after cold working than Grade 304.
A: We supply precision slit edge, deburred edge, rounded edge, and standard mill edge profiles depending on your tooling requirements.
A: As a global SS 316 Mirror Finish Strip Exporter and Stainless Steel 316 Strip Exporter, we regularly ship to Saudi Arabia, Qatar, Oman, Kuwait, Germany, Italy, Netherlands, Poland, Singapore, Malaysia, Vietnam, Indonesia, and the United States.
Partner with Nirvaan Overseas—your premier SS 316 BA Strip Supplier in India and SS 316 Mirror Strip Supplier in India—for direct warehouse pricing, custom coil slitting, laser PE protection, EN 10204 3.1 certification, and fast international dispatch. If you have any questions about the products or services, send us an
